Description

Greenerwave’s multi-orbit GEO/LEO user terminal is a state-of-the-art, energy-efficient, and electronically steerable antenna.

With its proprietary Reconfigurable Intelligent Surfaces (RIS) technology, Greenerwave ensures high-performance connectivity tailored for both Geostationary Orbit (GEO) and Low Earth Orbit (LEO) and satellites. Thanks to its innovative design, the terminal combines agility, robustness, and reliability to meet the growing demands of modern communication applications.

Specifications

FeaturesData
Dimensions~ 54 cm x 63 cm x 11 cm
Weight~ 14 kg
Operating Power Consumption< 110 W typical
Operating Temperature-40°C to +55°C
Protection IngressIP66
Rx Frequency10.7 GHz – 12.5 GHz
Tx Frequency13.75 GHz – 14.5 GHz
G/T9.0 dB/K
EIRP42 dBW
PolarizationLinear (H/V); Circular (RH/LH); Switchable
Antenna CoverageAzimuth: 360°
Elevation: 20° – 90°
1 6 - Greenerwave
2 3 - Greenerwave
3 4 - Greenerwave
4 4 - Greenerwave

Accessories

Fa GW 9dbK Blanche 2 - Greenerwave
  • AC/DC converter (included)
  • Battery kit: battery (99Wh), Charger (up to 3 batteries)
  • Tripod
  • Complementary power cable/ethernet cables
